US20M/US20S
The UltraSpeed series represents our top-tier enterprise SSDs, engineered for exceptional write performance and large capacity options. These drives are designed to deliver both scalability and operational efficiency while significantly lowering operating costs. With the latest form factors and a feature set that sets them apart, UltraSpeed Series offers tailored SSD performance with the convenience of an off-the-shelf purchase.
Key features
- Available capacities:
US20M: 1.92 – 30.72 TB US20S: 1.6 – 25.6 TB
- Capacity up to 30,72 TB
- PCIe 4.0 or PCIe 5.0 1x4 / 2x2 available in Single and Dual Port
- DWPD up to 3
| US20M | US20S | |
|---|---|---|
| Capacity | 1.92TB – 30.72TB | 1.6TB – 25.6TB |
| Interface | PCIe 5.0 1x4, 2x2 | PCIe 5.0 1x4, 2x2 |
| Form Factor | U.2 15mm/E3.S 1T | U.2 15mm/E3.S 1T |
| Sequential read (MB/s) | 14,800 | 14,800 |
| Sequential write (MB/s) | 8,700 | 8,700 |
| Random read (IOPS) | 3,200K | 3,200K |
| Random write (IOPS) | 460K | 930K |
| DWPD | 1 | 3 |
| Safety | AES-256 TCG OPAL 2.0 | AES-256 TCG OPAL 2.0 |
| NVMe | 64 Namespaces NVMe-MI over SMBus E2EDPP | 64 Namespaces NVMe-MI over SMBus E2EDPP |
| Other | Dual port PLP | Dual port PLP |
| Status | CS | CS |
